Technics SX-PX662 Service Manual

10.6. Removing the speakers
- Follow the (Step1)-(Step3) of item 10.1.
10.6.1. Removing the speakers
Remove 4 screws (refer to [Fig. 9] ).
[Fig. 9]
10.7. Removing the printed circuit boards
- Follow the (Step1)-(Step3) of item 10.1.
- Pull out the connectors on the printed circuit boards.
10.7.1. Removing MAIN, FJASP and HP P.C.B.
- MAIN P.C.B.
(Step1)
Remove the ground wire holding screw (refer to [Fig. 10] ).
(Step2)
Release the clows of the 5 P.C.B. holders (refer to [Fig. 10] ).
- FJASP P.C.B.
(Step1)
Remove the 4 screws ×2 and ×2 (refer to [Fig. 10] ).
10
