claw from the chassis (refer to [Fig. 5] ).
(Step3)
Lift the key and remove it.
[Fig. 5]
10.4.2. Disassembly (black keys)
(Step1)
While pressing slightly the front of the key, push the rear of the key forward to disengage the key
claw from the chassis (refer to [Fig. 6] )
(Step2)
Lift the key and remove it.
[Fig. 6]
10.4.3. Assembly (both white and black keys)
(Step1)
Insert the front part of the key into the chassis.
8
