Connecting a DVD Player/Recorder, Video Recorder or
Cable/Satellite Box
TVs Input/Source should be set to SCART
CONNECTIONS
Connections
RF I N
SCART
TV Aerial
Wall Socket
SCART
OUT
RF
IN
RF
OUT
DVD or VCR
A
B
D
L
M
F
E
H
G
J
K
MINI SCART 2X Mini SCART input
VGA(PC) VGA-PC input
HDMI 3X HDMI input
RF IN RF / TV Aerial Input
HEADPHONES 3.5mm Headphone output
CI CARD IN Common Interface Card Input
COAX OUT Digital Coax output
USB USB port
DLNA Network Port
AV IN AV Input
Component HD Component HD Input
COMPONENT AUDIO Component audio input
VGA(PC) Audio In 3.5mm PC audio input
