PG 15
Cleaning the gas hob
Remove the trivets (Refer Figure 1)
Removing the burner parts
(Refer Figure 2)
• The trivets locate in the recessed area of the hob.
• They can be removed for cleaning by carefully lifting
them from the hob.
• Clean by washing in warm soapy water. Dry thoroughly.
• Take care when replacing the trivets as dropping them
onto the hob may damage the enamelled surface.
• The burner caps and crowns are removable for cleaning.
• Flame port blockage should be removed by means of a match
stick or brush.
• If the caps, crowns and cups are heavily soiled, use a non-
abrasive cleaning compound.
• Do not clean them with abrasive or caustic type cleaners, or put in
a dishwasher as they will be damaged.
Cleaning the grill compartment
• Pull the grill tray out.
• Clean the sides an bottom of compartment with hot soapy water.
• If stronger action is needed use a non abrasivecleaner applied with a
nylon scourer.
• Cleaning the Oven
• Open the door fully.
• Remove oven shelves and side racks.
• Clean in hot soapy water.
• Thoroughly dry with a soft cloth to remove excess water that may be
present.
Refitting the burner crowns and caps
• The burner crown must be fitted correctly into the burner cup or damage will occur during operation.
• To do this, ensure that the 2 ribs on either side of the spark plug hole are positioned into the 2 slots on the
burner cup. (See figure 2).
• The burner cap is simply positioned over the top of the burner crown.
NOTE: When the burner is correctly fitted it will sit level on the hob. If ignition is dicult or fails after cleaning, or
the flames are not even around the burner, then either burner parts are not dry / parts have not been positioned
correctly or incorrect cap is fitted.
