PG 16
Cleaning the oven door / How to remove the oven door
For a more thorough clean, you can remove and disassemble the oven door.
Proceed as follows:
• Oven door structures 1 remove and assemble procedure:
• Open the door to the full extent (fig.1);
• Open the lever A completely on the left and right hinges (fig.2);
• Hold the door as shown in (fig.3)
• Gently close the door (fig.3) until left and right hinge levers A are hooked to part B of the door (fig.4).
• Withdraw the hinge hooks from their location following arrow C (fig.4).
• Rest the door on a soft surface;
• To replace the door, repeat the above steps in reverse order.
Removing the Inner Pane of Glass
• Triple Glazed oven door: Remove the top frame (G) by unscrewing the 2 screws, located on the left and right
sides
• Gently pull out the inner pane of glass (fig. 2). Also remove the centre pane of door glass, not shown here.
• Clean the glass panes with an appropriate cleaner. Dry thoroughly, and place on a soft surface.
• Now you can also clean the inside of the outer glass.
Cleaning the door glass
• Clean the glass door using non-abrasive products or sponges and dry it with a soft cloth.
• Do not use the oven without the inner door panes fitted correctly. When re-fitting inner glass door panes
ensure they go back in facing the same way they came out. The doors are coated with a very slight reflective
coating to reflect the heat back into the oven cavity and keep the outer door cooler to touch.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the glass.
