You can also use the WPS function in the network wizard. To do this first
select a WiFi network and then select the Press Buon or PIN option. You can
otherwise use Skip WPS to reach manual password entry.
To find out more about the current connection select Seings.
Select Manual seing, if you know your network parameters and would like to
configure them manually. Take note of the instructions on the display.
Select Delete network profile to delete connections no longer required.
If the network connection should be retained in standby, select Enable
Network Connection in Standby > Yes. However, doing so will increase the
power consumption.
12.3 Set-up wizard
On first switching on and aer a factory seings reset, the set-up wizard is
automatically launched.
> First select the Display Language and then > YES as soon as Perform now is
shown on the display.
If you select No, the wizard closes and you must perform the required seings
manually.
You will be taken through the seings in various steps.
> Under Time format, select the desired display format for the time display
(Section 12.1.3).
> During the next step you must select via which source the time is to be
synchronised (for more information refer to Section 12.1.2).
> You can then set up a WiFi network connection. For more details, see Section
12.2.
> Press theScroll&Select/Snooze knob to close the wizard when Set-up
Wizard Completed appears in the display.
12.4 Backlight
Under System seings > Backlight you can adjust the brightness of the display
for Operation and for Standby . You can choose between High, Medium and Low.
Confirm the selection by pressing the Scroll&Select/Snooze knob. Under Auto Dim
you can set the time aer which the display is automatically dimmed.

TechniSat TECHNIRADIO 5 IR Specifications

General

Radio type	Portable
Tuner type	Digital
DAB band range	174 - 240 MHz
Supported radio bands	DAB, UKW
Radio Data System (RDS)	Yes
RMS rated power	10 W
Number of built-in speakers	2
Display type	TFT
Display diagonal	2.4 \
Ethernet LAN	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Coloration	Monochromatic
Product color	Black
Volume control	Rotary
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, FRE, ITA, NOR, POL, SLV
Power source	AC/DC
AC input voltage	230 V
DC input voltage	8 V
AC input frequency	50 Hz
Battery capacity	2000 mAh
Storage temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package type	Box
Package depth	1500 mm
Package width	3530 mm
Package height	2400 mm
Package weight	2270 g

Weight and Dimensions

Depth	1140 mm
Width	270 mm
Height	1180 mm
Weight	1660 g
