54PLURIMA
M
N
H
Replacing the cable
Replacing the cable of the arms
There is only one cable for the two arms.
Remove the 2 straps: unscrew the pin with a 5 mm T spanner.
Lift the bumper (M) in both arms and remove the bush (N).
Pull the bumper (M) out.
W
Hold the pulley groups (H) as they could fall to the ground when the
cable is loosened.
