55PLURIMA
Q
H
O
P
R R
Replacing the cable
Take the cable out of the arm, then out of pulley (O) and then out of pulley (P).
Take the cable out of the pulley group (H); thread the cable through the frame
hole, then through the pulley (Q).
Loosen the two central pulleys (R) with an 8 mm T spanner and a 17 mm open-
ended spanner without removing them.
Loosen the pulley block on the crosspiece with a 17 mm adjustable spanner
and a 6 mm T spanner.
Take the cable out of the 3 pulleys.
