56PLURIMA
S T
U
H
R
Replacing the cable
Take the cable out of the pulley (S) and then from the pulley group (H).
Take the cable out of pulleys (T) and (U).
Take the cable out of the arm.
Repeat the steps indicated in the drawing to insert the arm cable.
Check that the cable is laid correctly in the grooves of all the pulleys.
Retighten the central pulleys (R) and the crosspiece pulley.
