75PLURIMA
E
D
P
Q
Replacing the cable
Insert the nut (E) in the cable.
Insert the cable in the adjustment screw housing (D) and then tighten the
nut (E).
Tighten the adjustment screw (D) in place.
Press against the hole (P) to release the pivoting element (Q).
Insert the cable in the arm and then in the pivoting element.
Insert the pivoting element (Q) once again making sure it clicks in perfectly.
