76PLURIMA
C
B
A
Replacing the cable
Insert the end of the cable in the bumper (B) and then in the bush (C).
Insert the open element (C) in the bumper (B).
Insert the ring of the handle in the bush and lock it with the pin (A); secure the
pin with a 5 mm T spanner.
Before remounting the guards and closing access to the inside parts, adjust
cable tension as described in the "Adjusting cable tension" paragraph.
