Technogym Skillmill Console - Cables; Cu Cables

2.8 CABLES
 
2.8.1 CU CABLES
CU0853: Cable A - Low Kit / UI board connection
(UI board connection / Patch connector)
UI board connection Signal Colour Patch connector
1  Yellow 1
2  Brown 2
3  White 3
4  Green 4
5  Grey 5
6  - -
CU0854: Cable A - TGS / NFC
(NFC / Patch connector)
NFC Board Signal Colour Patch connector
1  Yellow 1
2  Brown 2
3  White 3
4 - - -
5 - - -
6 - - -
7 - - -
8  Green 4
CU0855: 5V power supply cable
(Power supply/ Low Kit)
Low Kit board Signal Colour 5V input JACK
1  Red 1
2  Red 1
3  Black 2
4  Black 2
- - 3
