CU0889: 5V JACK cable
(Baery/5V jack)

(Jack with cast
cable)
Signal Colour 5V jack
1  Red 1
2  Black 2
CU0890: 5V USB cable
(Baery/5V jack)
Low Kit Signal Colour 
1 - - 2
2  Red 1
3  Black 4
4 - - 3
