Technogym SKILLROW - Cleaning the Fan

27
SKILLROW
A
B
E
C
B
D
F
G
CLEANING THE FAN
If braking is not ecient, clean the fan.
Unscrew the screw (A); hold the grille (B) with
one hand.
Unscrew the screws (C) to remove the grille (B).
Remove the protection (D).
Unscrew the screws (E) to remove the grille (F).
Use a vacuum cleaner to clean the grilles (B)
and (F).
Unscrew the screws (G) and clean the fan with a
vacuum cleaner.
Ret all the grilles.
Perform all the operations in reverse, following the
indicated order .To ret the grille (B) it is important
to rst tighten the screws (C), and only at the end
the screw (A).
