SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 18 -
ATTENTION: It is not recommended to have the power supply socket located below
the Skillrun.
LAYOUT 1 / 4:
ATTENTION: The LAYOUT 1 is the recommended layout.
Fig. 8 - Layout 1 recommended
Layout 4: make sure that the cables are long enough.
LAYOUT 2 / 3:
It is recommended to use a sheath for cables (to be provided by the customer) that guides the
bending of cables. Hereafter an example:
Fig. 9 - Layout 2 / 3 OK
