TecMate OptiMate Lithium 4s 0.8A - Page 2

Multi bank / station model OptiMate Lithium 0.8 x4 : each bank /station /
output operates as an independent OptiMate Lithium LFP 4s 0.8A
12.8V
LiFePO
4
1234
24-724-7
BmsBms
LED #1 AC POWER (100-240V)
LED #2 REVERSE POLARITY
LED #3 SAVE / SOC: 0 - 49%
LED #4 CHARGE / SOC: 50%+
LED #5 MAINTAIN / SOC: 70% - 100%
/ SOH:
LED #6 BATTERY SOH:
15
2
34
6
SOC - State Of Charge
SOH - State Of Health
6
6
0 - 30%
12.00 - 13.12V
0%
V < 12.00V
6
5
30% - 70%
13.13 - 13.19V
5
70% +
13.20V+
TEST
