P2012
AIRCRAFT MAINTENANCE MANUAL
2. Lubrication Charts and Schedule
Table 2 - Lubrication Charts
Description Reference Grease, item
Pedals bushing Refer to Fig.1 10 or equivalent
Rudder Steering Bellcrank bearing Refer to Fig.1 8, 9 or equivalent
Pedal tube attachments Refer to Fig.1 8, 9 or equivalent
Rudder control lines pulleys Refer to Fig.2 8, 9 or equivalent
Rudder control cable terminals Refer to Fig.2 8, 9 or equivalent
Control column structure point Refer to Fig.4 8, 9 or equivalent
Control Column Pulleys Refer to Fig.4 8, 9 or equivalent
Control Wheel Rod Joint Refer to Fig.4 8, 9 or equivalent
Aileron control pulleys Refer to Fig.5 8, 9 or equivalent
Aileron control rod terminal Refer to Fig.5 8, 9 or equivalent
Aileron bellcranks Refer to Fig.5 8, 9 or equivalent
Elevetor and Pictch Control Line -
Pulley on tailcone frame (if
MOD2012/188 is applied)
Refer to Fig.6 8, 9 or equivalent
Elevator Control Line - Rod
terminal
Refer to Fig.6 8, 9 or equivalent
Elevator Control Line - Bellcrank Refer to Fig.6 8, 9 or equivalent
Elevator Control Line - Trim
Actuator*
Refer to Fig.6 11 or equivalent
Elevator Trim Hinge Bushings Refer to Fig.13 10 or equivalent
Rudder Hinge Refer to Fig.8 8, 9 or equivalent
Flap Control Line - Bellcranks Refer to Fig.9 8, 9 or equivalent
Flap Control Line - Push Rod Refer to Fig.9 8, 9 or equivalent
Flap Control Line - Control Rod Refer to Fig.9 8, 9 or equivalent
Aileron Bushing Hinges Refer to Fig.14 10 or equivalent
NLG Lubrication Fitting Refer to Fig.11 8, 10 or equivalent
MLG Lubrication Fitting Refer to Fig.12 8, 10 or equivalent
NLG Wheel Bearing Refer to Fig.11 7
MLG Wheel Bearing Refer to Fig.12 7
Crew Door Hinge Refer to Fig.16 8, 9 or equivalent
Main Door Foot board Hinge Refer to Fig.15 8, 9 or equivalent
Door Rod bearing Refer to Fig.18 8, 9 or equivalent
Crew Door Foot board Hinge Refer to Fig.19 8, 9 or equivalent
RH Emergency Door Refer to Fig.20 8, 9 or equivalent
* Refer to follow note
