2.1.12 Approved Fuel
Min. RON 95 (AKI 91 Premium USA)
AVGAS 100LL (see Warning below)
Warning
Prolonged use of Aviation Fuel Avgas 100LL results in greater wear of valve seats and greater combustion deposits inside
cylinders due to higher lead content. It is therefore suggested to avoid using this type of fuel unless strictly necessary.
2.1.13 Powerplant Instrument Markings
Powerplant instrument markings and their color code significance are shown below:
Instrument
Red line
Minimum limit
Green arc
Normal
operating
Yellow arc
Caution
Red line
Maximum limit
Engine Tach Rpm
-------- 1400-5500 5500-5800 5800
Oil Temp. °C 50 90-110 50 - 90
110-130
130°C
Cylinder
heads temp.
°C -------- 50 - 135 --------
135°C
Oil pressure Bar 0.8 2 – 5 0.8 – 2
5 – 7
7
Fuel
Pressure
PSI 2.2 2.2 – 5.8 5.8
2.1.14 Other Instrument Markings
Instrument Red line
Minimum
limit
Green arc
Normal operating
Yellow arc
Caution
Red line
Maximum
limit
Voltmeter 10 Volt 12 - 14 Volt ---- ----
Suction gauge
(if installed)
4.0 in. Hg 4.5 – 5.5 in. Hg ---- ----
2.1.15 Weights
Maximum takeoff weight: 600 kg (1320 lbs)
Maximum landing weight: 600 kg (1320 lbs)
Maximum baggage weight: 20 kg (44 lbs)
2.1.16 Center of Gravity Limits
Forward limit 20% MAC 1.743 m (68,6”) aft of datum for all weights
Aft limit 33% MAC 1.925 m (75.8”) aft of datum for all weights
Datum Propeller support flange w/o spacer
Bubble Level Cabin floor
Warning
It is the pilot's responsibility to insure that airplane is properly loaded
