3.3.1 Loading
Baggage compartment is designed for a maximum load of 44 pounds. Baggage size shall prevent excessive loading of
utility shelf (maximum pressure 12.5 kg/dm2). Maximum baggage size is: 80x45x32 cm . Baggage shall be secured using a
tie-down net to prevent any baggage movement during maneuvers.
3.4 Equipment List
The following is a comprehensive list of TECNAM standard and optional supplied equipment for the P92 Eaglet. The list
consists of the following groups:
A. Engine and accessories
B. Landing gear
C. Electrical system
D. Instruments
E. Avionics
The following information describes each listing:
• Part-number to uniquely identify the item type
• Item description
• Serial number
Equipment list Date:
Ref. Description & p/n Weight kg Datum m
Engine & accessories
A1 Engine Rotax 912S2 or 912ULS 61.0 0.32
A2 Propeller Tonini
GT-2/173/VRR-SRTC FW101
6.0 -0.13
A3 Exhaust and manifolds - p/n 973670 4.50 0.55
A4 Heat exchanger - p/n 92-11-830 2.00 0.55
A5 Oil Reservoir (full) - p/n 956.137 4.00 0.64
A6 Oil radiator - p/n 886 025 0.40 0.07
A7 Liquid coolant radiator. - p/n 995.697 0.90 0.33
A8 Air filter K&N - p/n 33-2544 0.40 0.58
Landing gear and accessories
B1 Main gear spring-leafs - p/n 92-8-300-1 5.700 1.94
B2 Main gear wheel rims. - Cleveland 40-
78B
2.050 1.94
B3 Main gear tires.-Air Trac 5.00-5 AA1D4
2.580 1.94
B4 Disk brakes – Marc Ingegno 0.800 1.94
B5 Nose gear wheel rim - p/n 92-8-880-1 1.300 0.310
B6 Nose gear tire - Sava 4.00-6 1.200 0.460
B7 Nose gear fairing p/n 92-8-410-1/2 1.500 0.460
B8 Main gear fairing p/n 92-8-420-1/2 1.500 1.930
B9 Nose gear shock p/n 92-8-200-000 1.450 0.465
