1.10 Landing Gear
The main landing gear is realized with simple steel spring-leaves, 5.00x5 wheel and tires, disc brakes, renowed for their
operational record of effectiveness and safety.
Figure 1-5 Main landing gear
The nose gear features a steerable wheel with a rubber doughnut shock absorber.
Figure 1-6 Nose landing gear
Flight without wheel fairings can be conducted without significantly affect aircraft
performance and handling qualities.
