Instructions for the installation, use and maintenance of Tecnicomar watermaker
9-36
11
Stem elbow Ø10
201RP01010GC00
1
12
Adaptor for safety valve
A14TR000VLRG00
1
Models: SAILOR C 200 - 400 - 600 -1000 - 1500 , SAILOR S 1/21 – 2/21 – 3/21 - 2/40 – 3/40
(*)only for: SAILOR C 200 - 400 – 600; SAILOR S 1/21 – 2/21 – 3/21
MOTORIZED VALVE GROUP (fig. 2)
No.
PART NAME
ITEM CODE
QTY
1
Motorized actuator 24 AC/DC
211AT0140S0000
1
2
Ball valve for motorized actuator
211VLFF014GAS0
1
3
Threaded nipple 1/4”
201RX00014NNPT
1
4
Elbow reduction ¼”- 4mm
201RXM0144GNPT
1
5
High pressure hose 1/4”(+ fittings)
THP/…/1/4
1
6
Elbow ¼” – 7/16”
201RX71614GNJI
1
7
Stem adaptor ¼” -8
201RP00814DC00
2
8
Equal elbow Ø8
201RP00008G000
1
9
Safety valve ¼”
211VL0H9850000
1
10
Tee Ø8
201RP00010T000
1
11
Stem elbow Ø8
201RP00088GC00
1
12
Adaptor for safety valve
A14TR000VLRG00
1
Models: MINIMAR PL 200 – 400 - 600
PREFILTERS GROUP (fig. 3)
No.
PART NAME
ITEM CODE
QTY
1
Filter container 10”slimline
2801F158208000
2
2
Filter cap 10”slimline
2801F158208000
2
3
Elbow (with nut) M ½” – 5/8”
201RX01258GNPT
1
4
(Threaded) Nipple ½”
201RO00012NC00
1
5
Nipple ½”
201RO00012NC00
1
6
Cartridge 30 µm
2801C155017030
1
7
Cartridge 5 µm
2801C255482430
1
8
Tee fff ½”
201ROFFF12TC00
1
9
Reduction ½” – ¼”
201RO01214RC00
1
10
Hose barb m ½”-20
201ROM1220PC00
1
11
Straight m 10-1/4”
201RPM1014DNPT
1
12
O-ring
280OR151121000
2
When Automatic Membranes Flushing system isn’t installed 5,8,9,11 are substituted by :
A
Elbow mf ½”
201RXMF012G000
1
Models: SAILOR 200 - 400 - 600 -1000 - 1500 , SAILOR S 1/21 – 2/21 – 3/21 - 2/40 – 3/40
SOLENOID VALVE GROUP (fig. 4)
No.
PART NAME
ITEM CODE
QTY
1
Solenoid 3-way valve 12 VAC 50Hz ¼"
211VL2V0141250
1
2-a
2-b
Stem adaptor ¼” -10
Stem adaptor ¼” -8
201RP01014DC00
201RP00814DC00
3
3
3-a
3-b
Equal elbow Ø10
Equal elbow Ø8
201RP00010G000
201RP00008G000
3
3
4-a
4-b
Hose HTR Ø10
Hose HTR Ø8
201RPT0108PTFE
201RPHTR860NAL
3
3
5
Solenoid 3-way valve 12 VAC 50Hz ¼" (cable connector)
211VL2V0141250
1
(a) for models: SAILOR C 1000 – 1500 – 2000 – 2/40 -3/40 ; BICOMPACT
(b) for models: SAILOR C 200 - 400 – 600 - 1/21 – 2/21 – 3/21 ; MINIMAR PL 200 – 400 – 600
FLOWMETER and SALINITY PROBE GROUP (fig. 5)
No.
PART NAME
ITEM CODE
QTY
1-a
Reducer Ø12 - Ø10
201RP01210R000
1
2-a
2-b
Female adaptor 3/8” – Ø12
Female adaptor 3/8” – Ø8
201RPF1238D000
201RPF0838DBSP
1
1
3
Flowmeter transducer Ø
i
=8, 1-15 l/min
211TF0011508MM
1
4
Tee fff 3/8”
201RP00038T00F
1
5-a
5-b
Stem adaptor 3/8” - Ø10
Stem adaptor 3/8” – Ø8
201RP01038DC00
1
