7. PCBA BOM
Please get the official BOM from material team.
The picture you can get from the 5.PCBA MAINBOARD COMPONENTS.
SAP code
Description
Placement
Material model
15201118
BTB,T/H=0.6,6.65x2.0x0.58,24PIN,MOLEX
CN1
505066-2420
15201094
BTB,H0.6,PLUG,3.57*2*0.5,6PIN
CN1100
CPBA306-0102E
15201080
BTB,T/H=0.6,11x1.87x0.56,40PIN,ELCO
CN1300
24 5806 040 112 829+
15201082
USS RF CONN,T/H1.2,2.0x2.1x0.6,RFK
CN1311
8524A0000A00
15201036
RF-COAXIAL,2.0x2.0x1.0,ECT
CN1711
818000291
15201101
BTB,T/H=0.8,WH,4.5x2.58x0.79,10PIN,ACON
CN4
BB1R4-10KBJ03
15201097
BTB,T/H=0.8,WH,8.5x2.58x0.79,30PIN,ACON
CN4403
BB1R4-30KBJ03
15301303
TFLASH,TRAY,17.63*16.0*1.43,8PIN
CN5203
CAF11-08143-0300
15301342
SIM-DUAL,26.73*19.06*1.45,T-terminal
CN6
CTF-G1131-0069
15301337
JACK,B/S,12.5x8.1x3.8,5pin,JITS
CN6001
C-1020160144
15201107
BTB,T/H=0.8,2.3x4.7x0.77,10PIN,0.4 母头 ATC
CN7
ASE5S1010
14601110
LED-Flash,200lm@1A,2.04*1.64*0.78
LED1
NLW2016AY2-YFK4-B55
14601127
LED-Flash,70lm@350mA,center=0.3,H=1.95
LED2
A-SL680AW1D-HA3A-2T
15600065
CPU-2G/W,4-A7@1.3GHz,8MP,HD,H1.1（CS）
U1001
MT6580A/WAHH_D
15600094
IC_CPU_MT6580A/WAZA
U1001
MT6580A/WAZA
14901034
TCXO-26M,0.5ppm,2.5*2*0.8,TXC
U1101
7L26002009
15700017
IC_PMU_MT6350V/AN
U2001
MT6350V/AN
14500001
IC-SENSOR,3axis,MXC4005XC
U3
MXC4005XC
14301096
IC-TXM,QB-G/G+4TRX,6*6*1.05,VC7584-51
U3101
VC7584-51
14301023
IC-PA,W-B1,3*3*1.1
U3201
VC5341-21
14801165
IC-DUP,W/FL-B1,1.8*1.4*0.6,D6RB2G140E1AL
U3206
D6RB2G140E1AL
14401132
IC_Charge,bq24259
U3227
BQ24259RGER
14201155
IC-eMMC+LPDDR3,16GB+8Gb,H1.0,SAMSUNG3
U4001
KMFE10012M-B214
14601099
IC-Serial LED Driver,TDFN2x2-6L
U4311
AW9961DNR
14601114
IC-Flash Driver,SGM3785YTDP14G/TR
U4401
SGM3785YTDP14G/TR
14801172
IC-LNA-GPS,1.5*1.0*0.75,MXDLN16GX
U5001
MXDLN16GX
14801119
SAW-GPS/BD/GLON,SAFFB1G56KB0F0AR15
U5002
SAFFB1G56KB0F0AR15
14801033
IC-TRIP,W/B/G,1.6*0.8*0.7
U5003
DP1608-V1524CAT/LF
14501040
IC-PS&ALS&LEDsensor,4.54*2.96*3.6
U5338
STK3311-W34
14701019
IC-AMP,AB/D CLASS,0.65W/0.85W,H0.6,2
U5339
AW8155AFCR
