Tecno L9 - Material Bom

V1.0
Carlcare Technical Training
PAGE
DOC NAME
AUTHOR
PAGE 9 (20)
TECNO_L9_Service Manual_V1.0
Lin Hongqiang
SECURITY
RELEASE TIME
VERSION
CONFIDENTIAL
12
th
April,2017
V1.0
6. MATERIAL BOM
Please get the official BOM from material team.
The picture you can get from the 3.EXPLODED VIEW and 4.EXPLODED EXPANSION.
CODE
CHINESE DESCRIPTION
ENGLISH DESCRIPTION
12102417
PCBA_MB_H8012_A1_16GB+8Gb_V1.3_自制
PCBA MB H8012 A1 16GB+8Gb V1.3
12102416
PCBA_SUB_H8012_1_A_V1.3_自制
PCBA SUB H8012 1 A V1.3
17201355
CAM_5M_GC5024_L9 Plus_FRONT_ST
CAM 5M GC5024 L9 Plus FRONT ST
17201286
CAM_8M_3H7_X557_BACK_SUNNY
CAM 8M 3H7 X557 BACK SUNNY
19301070
MOT_COIN_0827_L12_H_带导电胶_LL
MOT COIN 0827 L12 H LL
19401107
SPK_1115_SPR_H3.0_铝膜_RoHS_HS
SPK 1115 SPR H3.0 RoHS HS
19101074
同轴线_IV 代_RF_CONN_101.5mm_L9
coaxial cable IV RF CONN 101.5mm L9
19501038
REC_1206R_H24_H 弹片_高 SPL_ROHS_20mW_DS
REC 1206R H24 H SPL ROHS 20mW DS
19501043
REC_1206R_H24_H 弹片_方磁_RoHS_20mW_QD
REC 1206R H24 H flexible RoHS 20mW QD
23001374
FPC_侧键_L9_H8012_38.1*13.39*0.93mm
FPC Sidekey L9 H8012 38.1*13.39*0.93
25001221
BAT_TECNO_BL_39DT_3900mAh_ATL_IN
BAT TECNO BL 39DT 3900mAh ATL IN
23701130
电池指纹连机器钢片组件_L9
battery steel plate assembly L9
23701132
CTP 连接器压紧钢片组件_L9_银色
CTP Steel L9 silver
23201530
后摄像头镜片_L9_玻璃_厚 0.5mm_黑色
camera lens L9 0.5mm
23501860
距离感应器胶套_L9_黑色
sensor glue set L9 black
23501815
咪头密封胶套_L9 Plus_黑色
MIC rubber L9 Plus black
23501816
耳机座密封胶套_L9 Plus_黑色
earphone rubber L9 Plus black
23303046
指纹模组 PC 垫片_9.5*11.5*0.8mm_L9
FP PC gasket L9
23303044
前 CAM 支撑钢片导电布_6.7*6.0*0.07mm_L9
frontCAM conductive fabric L9
23303045
指纹模组接地导电海绵_13.2*1mm_L9
FP conductive foam L9
23501861
耳机座背面密封胶套_L9_黑色
earphone seat rubber L9 black
23303000
前摄像头密封泡棉_7.2*0.5mm_L9
Front CAM foam 7.2*0.5mm L9
23302961
听筒接地导电海绵_5*5mm_L9 Plus
REC conductive foam 5*5mm L9 Plus
23302963
后摄像头导电布_16*8mm_L9 Plus
back CAM conductive fabric L9 Plus
23303002
电池易拉胶_50.3*7.6*0.15mm_L9
battery cover 50.3*7.6*0.15mm L9
23400002
机械螺钉 M1.4*L2.5*D2.5*H0.5_银色_打防松胶
Screw M1.4*L2.5*D2.5*H0.5 silver glue
23800105
防水贴_3mm_RoHS
Waterproof_label RoHS
23800040
易碎标贴_D2.5mm_RoHS
Fragile_label D2.5mm_RoHS
23801510
贴纸_售后 IMEI 标签_5*9*0.08
sticker warranty IMEI lable 5*9*0.08
23800050
IMEI 码标贴_40*34mm_RoHS
Dual_IMEI_code_Label_40*34MM_RoHS
23303305
后摄导电布_14.5*8*0.07mm_L9
Camera conductive cloth _14.5*8*0.07mm
12201372
预加工组件_面壳+LCD 组件_L9_金色
PF uphousing+CTP L9 gold
17401255
组合件(LCD+CTP)_5.5HD_L9_香槟金_RoHS
module(LCD+CTP) 5.5HD L9 champgold
21001656
面壳组件_L9_PC+镁铝合金_金色
housing L9 PC+ mag gold
12201373
预加工组件_电池盖+指纹模组_L9_香槟金
PF batterycover+FP L9 champgold
17600113
指纹模组(SW9251)_L9_香槟金_OFilm
FM(SW9251) L9 champgold OFilm
21201955
电池盖组件_L9_PC+铝合金 5252_香槟金
battery cover L9 champgold
23501856
天线支架组件_L9_PC_黑色
ANT assembly L9 PC black
23501857
摄像头装饰件组件_L9_香槟金
CAM deco L9 champgold
23401097
机械螺钉_M1.0*L3.5*D1.6*H0.5_银色
screw M1.0*L3.5*D1.6*H0.5 silver
23501858
SIM 卡托组件_L9_香槟金
SIM card holder L9 champgold
23501859
TF 卡托组件_L9_香槟金
TF card holder L9 champgold
23601563
电池盖贴膜_两层_TECNO_L9
battery cover protector TECNO L9
23601562
贴膜_三层_TECNO_L9
LCD protector TECNO L9
