Tecno L9 - Exploded Expansion

V1.0
Carlcare Technical Training
PAGE
DOC NAME
AUTHOR
PAGE 6 (20)
TECNO_L9_Service Manual_V1.0
Lin Hongqiang
SECURITY
RELEASE TIME
VERSION
CONFIDENTIAL
12
th
April,2017
V1.0
4. EXPLODED EXPANSION
23501816
earphone rubber L9 Plus black
23501861
earphone seat rubber L9 black
23501860
sensor glue set L9 black
23501815
MIC rubber L9 Plus black
23701130
battery steel plate assembly L9
23701132
CTP Steel L9 silver
23001374
FPC Side key L9 H8012 38.1*13.39*0.93
23303046
FP PC gasket L9
