GENERAL NOTES &
Thank you for purchasing one of the many products
manufactured by TECNOMAGNETE S.p.A.
This manual is designed to help you become familiar
with your new product and must therefore be care-
fully read and followed.
For further information on the system, you can con-
tact TECNOMAGNETE’s technical support at any
time.
The descriptions and illustrations provided in this
manual are for reference only.
While conrming the general characteristics
of the controllers described in the manual,
TECNOMAGNETE S.p.A. reserves the right, at its
discretion, to change at any time some of the char-
acteristics in order to improve the product or due to
manufacturing and commercial reasons. The neces-
sary updates, if required, shall be supplied as attach-
ments.
This manual is property of TECNOMAGNETE S.p.A.
and cannot be copied in whole or in part or made
available to third parties without the written authori-
zation of the manufacturer. Should the products be
amended and/or updated, upon authorization of
TECNOMAGNETE S.p.A., the manufacturer shall
integrate the existing manual by providing the text
explaining the use of the modied/integrated com-
ponent along with a description of potential residual
risks.
1.1 Overview of the company
TECNOMAGNETE started its activities in 1972 as
manufacturer of permanent-electro magnetic sys-
tems designed to ensure power, exibility and maxi-
mum safety. Its state-of-the-art technologies and the
patents developed over the years have enabled the
company to become a leading supplier in several
international markets.
The permanent-electro magnetic systems manufac-
tured by TECNOMAGNETE are able to produce all
the magnetic force required both to clamp and lift
work pieces, thus eliminating the need of using elec-
tric power during machining.
Its main elds of activity include:
CLAMPING SECTION FOR LIFTING
•
MTE permanent-electro lifters designed to ena-
ble the handling of ferrous loads of any shape and
dimension.
•
BAT-GRIP permanent-electro lifters with incor-
porated battery.
•
MaxX manual lifters.
WORK HOLDING LINE
•
QUADSYSTEM chucks for millers and machining
centers of all sizes.
•
TFP0 and TFP1 for high precision grinding.
•
RADIAL-POLE chucks for nishing or roughing
operations on boring mills.
•
QUAD-RAIL modules to clamp rails of varying
lengths.
•
MDS chucks for EDM machines.
STAMPING and MOLDING LINE
•
QUAD-PRESS systems to clamp molds.
TECNOMAGNETE has installed approximately
50,000 units in over twenty years, thanks mainly to
its wide-ranging offer, its exibility to meet custom-
ers’ requirements and its efcient post-sales serv-
ice.
