- 21 -
Touch Control
Phase 1
Phase 1
- Disconnect the aluminium panels.
Phase 2
- Unscrew the screws as shown in the picture.
Phase 3
- Take away the control support.
Phase 4
- Disconnect the flat cable.
Phase 2
Replacing the touch control 10.1
Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply.
Phase 3
Phase 4
