Tecnowind EAGLE - Page 30

- 30 -
Power board
Phase 1
Phase 1
- Unscrew the 5 screws as shown in the picture
Phase 2
- Disconnect the at cable and the electrical pins. Now you can
replace the power board.
ATTENTION!
during the reassembling phases be carefull because there is only
one correct way to connect the flat cable. All the electrical pins
must be reassembled in the right position. Refer to the wiring
diagram.
Phase 2
