- 36 -
Phase 7
Phase 7
- Separate the RIGHT impeller housing from the LEFT
Phase 8
- Remove the plugs from the motor support.
Phase 9
- Remove the screws which secure the motor to the impeller hou-
sing.
- Replace the motor, unsoldering the electrical wires and resolde-
ring them on the new motor
Please note!
To reassemble the parts, the operation must be carried out in re-
verse.
Phase 8
Phase 9
Motor
