10 User’s manual - TECO 22 - 23 - 25 - 27 Special
DESCRIPTION
The machine is a electro-pneumatic tyre changer semi-automatic, to be used with wheels with drop
centre featuring weights and dimensions as described in the technical data section.
It is designed to work effectively on:
- Conventional wheels;
- Reverse rim wheels or wheels without central hole (use optional kit);
- Run-at tyres with reinforced sidewalls*.
* WARNING: There are specically studied procedures for this type of wheels.
NB: It may be difcult and sometimes impossible to clamp and/or demount wheels of Vintage
cars (cars out of production for over 30 years), some types of rally wheels and non-standardized
street wheels.
The machine is solidly constructed. It operates with the wheel in a vertical position for bead breaking
and horizontal for mounting and demounting tyres. All machine movements are controlled by the
operator by means of the pedals.
MANUFACTURER’S LABEL
Each machine carries a plate with its identication and some technical data.
As well as the manufacturer’s details, it indicates:
Mod. - Machine model;
V - power supply voltage in Volts;
A - Input voltage in Amperes;
kW - Absorbed power in kW;
Hz - Frequency in Hz;
Ph - Number of phases;
bar - Operating pressure in bar;
Serial No. - Machine serial number;
EC - EC marking.
Mod.
Ser. N.
Volt
Kw
Amp.
Year
Weight
Ph
Hz
Bar
Automotive Equipment
TECO s.r.l. Via Pio La Torre 10
42015 Correggio (R.E.) - ITALY
tel. 0522/631562 - fax 0522/642373
WARNING
It is forbidden to modify or remove the data in the plate.
