TECO 22 User Manual

28 User’s manual - TECO 22 - 23 - 25 - 27 Special
1
3 5
7
9 11
2
4
6
8
10 12
0
RL
3 Ph ~
L2 L3
PE
XS1 SPINA E PRESA Plug & Socket
INVERTITORE COMMUTATORE DI POLARITA’ Reverse Polarity Switch
x 11-12
x 9-10
x 7-8
x 5-6 x 3-4
x 1-2
L 0 R
1 2 3
L1
ELEMENTI - Elements
CONTATTI - Contacts
W2
U1
U2
V2
V1
W1
W2
U1
U2
V2
V1
W1
200-220-240V
380-415-440V
MORSETTIERA Junction Box
F F F
Power
Phase
400V / 3 / 50 Hz - 0,55 kW 500V, 4A 400V / 3 / 50 Hz - 0,75 kW 500V, 6A 230V / 3 / 50 Hz - 0,55 kW 250V, 10A 230V / 3 / 50 Hz - 0,75 kW 250V, 10A
200V / 3 / 50 Hz - 0,75 kW (Japan) 250V, 10A
F: Fuse

TECO 22 Specifications

General

Model	TECO 22
Self-centering chuck	Yes
Bead breaker force	3.5 tons
Operating pressure	8 bar
Air Pressure	8 bar
