User’s manual - TECO 22 - 23 - 25 - 27 Special 7
INSTALLATION CLEARANCES
WARNING
The installation site must be chosen in strict compliance with the relevant regulations regarding
Safety in the workplace.
IMPORTANT: for correct, safe use of the equipment, users must ensure a lighting level of at least
300 lux in the place of use.
CAUTION
The installation of the machine must be performed in a dry area which must be protected
from adverse weather conditions.
Install the tyre changer in the chosen work position, complying with the minimum clearances shown
in g. 3, adjust the height of the bead breaking support foot so that the machine is correctly posi-
tioned on the ooring.
Place the machine so that the plug-socket combination is easily accessible.
The machine must be placed on a horizontal surface, preferably concrete or tiled oor. Do not install
on unstable or damaged surfaces.
The surface on which the machine rests must withstand the loads transmitted during operation. The
surface must have a load-carrying capacity of at least 500 kg/m2.
Ambient working conditions
- Relative humidity 50% (temp. 40°C) ÷ 90% (temp. 20°C) without condensation.
- Temperature 5°C ÷ 40°C.
WARNING
Use of the machine in a potentially explosive atmosphere is not permitted.
A
B
5
4
®
