TECO 22 User Manual

User’s manual - TECO 22 - 23 - 25 - 27 Special 15
WARNING SIGNALS
PAY THE UTMOST ATTENTION TO THE WARNING LABELS ATTACHED TO THE MACHINE.
USING THE MACHINE WITHOUT READING THE WARNING SIGNALS MAY BE
SERIOUSLY DANGEROUS FOR THE OPERATOR.
DANGER OF CRUSHING PARTS OF THE
BODY BETWEEN THE BEAD BREAKER AND
THE MACHINE
C
DANGER OF HAND CRUSHING
BETWEEN CLAMP AND RIM.
DANGER OF HAND CRUSHING
BETWEEN MOUNTING HEAD
AND WHEEL.
D
CAUTION: AIR BLAST.
MAX. AIR SUPPLY LINE
PRESSURE 16 BAR
E
INFLATING GUN CONNECTION.
DO NOT DIRECTLY CONNECT
THE COMPRESSOR.
(only on standard version)
CAUTION: ELECTRIC CURRENT
DANGER OF CRUSHING PARTS OF THE
BODY BETWEEN THE BEAD BREAKER AND THE
WHEEL.
DANGER OF CRUSHING PARTS OF THE
BODY BETWEEN THE BEAD BREAKER ARM
AND THE MACHINE.
A
CAUTION: TOWER TILTING
000103700
000103500
000103000
000103100
000102800
F
000102700
G
000103600
H
I
J
000103400
000103200
000103300
B
®
D
G
B
H
I
J
F
A
C
E

TECO 22 Specifications

General

Brand	TECO
Model	22
Category	Tyre Changers
Language	English
