User’s manual - TECO 22 - 23 - 25 - 27 Special 5
TRANSPORT, STORAGE AND HANDLING
Conditions for transporting the machine
The tyre changer must be transported in its original packing and stowed in the position shown on
the external packing.
- Packing dimensions (Teco 22 - 23 - 25 - 27 Sp.):
• width ................................................................................................................................765 mm
• depth ...............................................................................................................................980 mm
• height ...............................................................................................................................970 mm
- Weight of the machine with packing (Teco 22 - 23 - 25 - 27):
• standard ............(TECO 22: 170kg; TECO 23: 183kg; TECO 25: 193kg; TECO 27 Sp.: 200kg)
• t.i. version ......................................(TECO 23: 198kg; TECO 25: 208kg; TECO 27 Sp.: 215kg)
Ambient conditions for machine transport and storage
Temperature: -25° ÷ +55°C.
WARNING
Do not stack other goods on top of the packing to avoid damaging it.
Handling
To move the packing, insert the tines of a fork-lift truck into the slots on the base of the packing itself
(pallet) (g. 1).
ATTENTION
Carry out the moving operations with great care, paying attention to move the packaged machine
only from the side clearly indicated on the packaging.
Failure to follow these recommendations may result in damage to the machine and put the operator’s
safety at risk.
Before moving the machine, refer to the HOISTING/HANDLING section.
1
1a
