16
• 2.5 Specifications of terminal wiring
• 2.5.1 Wiring specification
E710 series
Wiring diameter AWG (mm
2
)
NFB
*4
MC
*4
Power
Supply
Motor(HP)
*1
Rated
Current
(A)
main
Terminal
*2
Ground
E(G)
Control
Terminal
*3
200V
0.5HP 2.8
14~12
(2～3.5)
14~12
(2～3.5)
24~16
(0.2～
1.5)
TO-50EC(15A) CU-11
1HP 4.8
2HP 7.5
12~10
(3.5～5.3)
12~10
(3.5～5.3)
TO-50EC(20A) CU-11
3HP 11
10
(5.3)
10
(5.3)
TO-50EC(30A) CU-11
5HP 17
8（8.4） 8（8.4）
TO-50EC(30A) CU-16
7.5HP 25
8（8.4） 8（8.4）
TO-100S(50A) CU-18
400V
3 Ø
1HP 2.7
14~12
(2～3.5)
14~12
(2～3.5)
TO-50EC(15A) CU-11
2HP 4.2
14~12
(2～3.5)
14~12
(2～3.5)
TO-50EC(15A) CU-11
3HP 5.5
14~10
(2～5.3)
14~10
(2～5.3)
TO-50EC(15A) CU-11
5HP 9
12~10
(3.5～5.3)
12~10
(3.5～5.3)
TO-50EC(15A) CU-18
7.5HP 13
10
(5.3)
10
(5.3)
TO-50EC(20A) CU-18
10HP 17
8（8.4） 8（8.4）
TO-50EC(30A) CU-25
• 2.5.2 Terminal specification suggestion
2.5.2.1 Main Terminal
