TECO JSDEP-20A - I;O Terminal

17
2-2 I/O Terminal
There are 4 groups of terminals, which control signal terminal (CN1), encoder terminal (CN2) and
communication connector (CN3/CN4). The diagram below displays all positions for the terminal.
CN1 (25 pins Female)
Control Signal Terminal
CN2 (9 pins Female)
Encoder Terminal
CN3, CN4 (8 pins Female)
Communication Connector
8
6
3
5
1
2
1
13
14
25
1
5
9
6
