IMPORTANT NOTE:
Install this device only when it complies with local/national legislation, regulation and standards. This pro-
duct is intended to be used as an air conditioner in residential houses and is only suitable for use indoors
in dry locations, in normal household conditions, like living rooms, kitchens, and garages. This device is
suitable exclusively for earthed sockets, connection voltage 220-240 V~/ 50 Hz.
This manual is intended for persons with sufficient knowledge and experience with electrical devices, elec-
tronics, cooling technology and mechanical installations. Attempting to install or repair the device can cause
injuries and damaged properties. The manufacturer neither the vendor is responsible for the interpretation
of this information, and shall not be liable for the inefficient use of this information.
The information, specifications and parameters can be changed as a result of technical modifications or
improvements, without prior notice. The correct specifications are specified on the identification plate.
• Read this installation manual carefully before installing the product.
• A damaged power cord may only be replaced by qualified personnel.
• This device may only be installed in compliance with the applicable national and European require-
ments and by authorised personnel. The guarantee is invalid for damage caused by neglect or actions
that deviate from those in the user manual.
• Always wear appropriate personal protective equipment like goggles, face mask, ear protection, gloves
etc.
Internet:
In order to provide a better service, you can download the latest version of the user, installation, or service
manual at pvg.eu.
G
WARNING!
Don’t install, remove or reinstall the device yourself if you don’t have the required knowledge or
authorisation regarding electricity, electronics, cooling technique or mechanical installation.
• Improper installation can lead to water leakage, electrical shocks, refrigerant leakage or
fire. Refer to an authorised dealer or air conditioning specialist for the installation.
Attention: Malfunctions caused by improper installation are not covered by the guarantee.
• The unit has to be installed in an easy accessible place. All extra costs for renting special
equipment for servicing the unit are at the expense of the client.
CONTENTS
1. Safety precautions
2. Parts supplied
2.1 Parts supplied for the TSCS 8xx- 10xx models
2.2 Parts supplied for the TS 8xx models.
3. Activities prior to the installation of the air conditioner for the TSCS 8xx- 10xx models.
4. Activities prior to the installation of the air conditioner for the TS 8xx models.
5. Positioning of the indoor and outdoor unit.
5.1 Positioning of the indoor unit for the TS 8xx and TSCS 8xx -10xx models.
5.2 Positioning of the outdoor unit for the TS 8xx and TSCS 8xx -10xx
models.
6. Possible options for installing the piping from the inside unit to the outside unit.
7. Mounting the installation plate and drilling holes for piping.
7.1 Mounting the installation plate of the indoor unit.
7.2 Drilling holes for piping, condensed water hose and power cable.
8. Connecting the refrigerant piping.
8.1 Connecting and disconnecting the refrigerant piping for the TSCS 8xx- 10xx models.
8.2 Connecting the refrigerant piping for the TS 8xx models.
9. Connecting the condensed water drain for the TSCS 8xx- 10xx and TS 8xx
models.
9.1 Connecting the condensed water drain of the indoor unit.
9.2 Connecting the condensed water drain of the outdoor unit.
10. Electrical installation.
11. Connecting the power cables.
11.1 Connecting the power cables for the TSCS 8xx- 10xx models.
11.2 Connecting the power cables for the TS 8xx models.
12. Vacuuming the cooling system of the TS 8xx models.
13. Checking leak tightness of the cooling system for the TSCS 8xx- 10xx and TS 8xx models
models.
14. Adding refrigerant with pipe lengths over 5 meter.
15. Test run after installation for the TS 8xx and TSCS 8xx- 10xx models.
