3
fault.Markandredtagthecompressortoindicatethatthereisagroundfault.Donotrecon-
nectthepowerleads.Tapeandinsulateeachpowerleadseparately.
• Disconnectpowerbeforeservicing.Alwaysdisconnectpowerbeforeservicingunless
it is required for a specific troubleshooting technique. In these situations, use extreme
caution to avoid electric shock.
FIGURE 1-1: Compressor
with (1) protective cover and
(2) bale strap removed to
show (3) hermetic terminal.
FIGURE 1-2: Close up view
of hermetic terminal show-
ing individual terminal pins
with power leads removed.
FIGURE 1-3: Close up view
of hermetic teminal after it
has vented.
FIGURE 1-4: Compressor
with (1) protective cover
held in place by (2) metal
bale strap.
FIGURE 1-5: Compressor
with (1) protective cover
held in place by (2) nut.
FIGURE 1-6: Compressor
with (1) snap in protective
cover.
