Tecumseh AH5540E User Manual

11
A Standard Unit •
B Std. Unit W/Receiver Tank • •
C Std. Unit W/Receiver Tank & BX Cable • • •
D Std. Unit W/BX Cable • •
E,F,K Physical Design Variant (Conduit) • • •
G,H,J,L,P Physical Design Variant (Standard) • •
M Advanced Commercial Design • • • •
N Advanced Commercial Design • • •
S Customer Special •
T Interconnect Compressor •
U Water Cooled - Adv. Commercial Design • • • •
V Electrical Special (Conduit Design) • • •
W Water Cooled Unit • • •
X Interconnect Unit • • • •
Y Air Water Cooled Unit • •
Z Electrical Special (Standard Unit) • •
Evaporative Condensate Units Plastic Base
EC Large Evaporative Condensate Units Black Plastic Base •
ED Large Evaporative Condensate Units Black Plastic Base •
EE Large Evaporative Condensate Units Black Plastic Base •
GC Small - Fan Guard, Power Cord, Receiver Tank, Service Valves •
GB Small - Fan Guard, Power Cord, Receiver Tank •
GK Small - Fan Guard, Power Cord
GL Small - Fan Guard
Outdoor Condensing Units
HL Outdoor Condensing Unit with Options • •
Celseon
®
Air Cooled Units
CB
Std. Unit W/EC Fan Motor, Sweat Conns, Power Cord &
Receiver Tank
• •
CC
Std. Unit W/EC Fan Motor, Sweat Conns, Power Cord,
Receiver Tank & Service Valves
• •
CK Std. Unit W/EC Fan Motor, Sweat Conns, Power Cord •
CS
Std. Unit W/EC Fan Motor, Sweat Conns, Power Cord &
Service Valves
•
SB
Std. Unit W/SP Fan Motor, Sweat Conns, Power Cord &
Receiver Tank
• •
SC
Std. Unit W/SP Fan Motor, Sweat Conns, Power Cord,
Receiver Tank & Service Valves
• •
SK Std. Unit W/SP Fan Motor, Sweat Conns, Power Cord •
SS
Std. Unit W/SP Fan Motor, Sweat Conns, Power Cord &
Service Valves
•
The letters I, O, and Q are eliminated
Interconnect Compressor BX Cable Receiver Tank Air Water Cooled Water Cooled Fan Cooled See B/M Accumulator
Condensing Unit
Model Number Codes
E and G = Evaporative Condensate Units
S = Shaded Pole Fan Motor (Celseon)
C = Electrically Commutated Fan Motor (Celseon)
X = A holding character, reserved for future use
H = Housed Unit
Condensing Unit Features, see chart below
AEA4440YXA XC
FIGURE 2-2: Condensing Unit model number codes
