Teeter DEX II - Items for Assembly

2
Items for Assembly
Items not shown to scale. Hardware drawings located on the insert inside each Hardware Kit.
Base Assembly
Use with Base Assembly
Hardware Kit (D11019)
ITEM NO. ITEM NAME
Base Assembly
H12009 Base Frame
H12018 Derattler Knob
D11012 Two (2) Base Feet
H12010 Two (2) Legs
D11013
Two (2) Leg Feet
Lap Pad Assembly
H12006 Lap Pad Frame
D11005 Lap Pad
ITEM NO. ITEM NAME
Leg Support Assembly
H12016 Leg Support Adjustment Knob
H12019 Leg Support Shaft
Tools Provided for Assembly
H12014 Two (2) Wrenches (13/14mm)
H12015 Screwdriver
D11005
H12006
Lap Pad Assembly
Use with Lap Pad Assembly Hardware Kit (D11020)
H12016
H12019
Leg Support Assembly
Use with Leg Support Assembly
Hardware Kit (D11021)
H12014
H12015
Tools Provided for Assembly
H12010
D11012
D11013
H12009
H12018
