Adjust the Height of the Lap Pad:
The Lap Pad needs to be adjusted so that while standing on the Base
Frame platform, your hips are aligned with the top edge of the Lap Pad
(Figures 7a and 7b).
1. Loosen the Derattler Knob by rotating it several turns
counterclockwise (Figure 8).
2. While holding the Height Adjustment Handle on the Lap Pad, pull
the Height Adjustment Locking Pin and lift or lower the Lap Pad to
your ideal height (Figure 9).
3. Release the Locking Pin so that it engages fully into one of the height
settings. Tighten the Derattler Knob by rotating clockwise.
User Settings
FIGURE 8
FIGURE 9
FIGURE 7a
FIGURE 7b
8
