STEP
5
Attach Leg Support Assembly to Lap Pad Assembly
• Locate the Leg Support Assembly Hardware Kit (D11021).
• Thread the washers onto the bolts.
• With the Leg Support Adjustment Knob facing down, slide the Leg
Support Shaft into the receiving end of the Lap Pad Assembly
(Figure 5).
• Lining up the two holes, insert the Hex Bolts with washers. Secure
with one of the wrenches provided.
• Test the Lap Pad for smooth and steady rotation and that all fasteners
are secure:
» Stand between the Cane Shaped Handles with your body facing
the machine.
» Grasp the Traction Handles and rotate the Lap Pad towards you,
» Apply your full weight to the Traction Handles by lifting your legs
off the floor and lightly bouncing (Figure 6).
FIGURE 5
ALWAYS ensure that all parts are assembled correctly and read the User Settings/How to Invert thoroughly
before using your Teeter DEX II
™
. Improper assembly or settings could result in serious injury or death!
FIGURE 6
WARNING
!
7
