Tekno RC EB48.2 - Bag A: Center Differential Assembly

TKR5145
TKR5144
Bag A
Center Differential
(overview)
TKR5112X
TKR5112X
TKR5237
TKR5149
TKR5150
TKR5150
TKR5143
TKR5113
*TKR5115
*TKR5237K
(Option)
Step
A-2
TKR1325
M3x14mm Flat Head Screw
x4
TKR5144
TKR5145
Step
A-1
Fill with 7000 wt oil to
1mm below full
TKRBB08165
Ball Bearing(8x16x5mm)
x2
TKR5144
Differential 0-rings
x2
TKR5145
Differential Shims (6x17mm)
x2
TKR1325 x4
TKRBB08165
Diff
Oil
TKR5150
3
Step
A-4
Step
A-3
Grease
Grease
Grease
Grease
