Operators Familiarization
Characters are selected by placing the underline within the Name of
Record brackets < > with the |¢ OR DELAY control. To select a
character over the underline, rotate the -{ control until the desired
character Is displayed, then move the underline to the right with the
t¢.OR DELAY control. Repeat the selection procedure until the name
of the record Is completed.
SETUP: xx—Displays the setup number from 01 through 20 of the
displayed record as on page 1 of Store/Recall Setup menu. When the
number is underlined with the k- OR DELAY control, the displayed
record can be changed with the -4 control. This allows specific records
to be reviewed and altered.
Status
of
Record—Iindicates
the
status
(EMPTY,
END
SEQ,
DELETED,
or
blank)
of
the
currently
displayed
record.
EMPTY
appears
only
when
there
are
no
stored
front-panel
setups.
END
SEQ
Is
the
end-of-sequence
Indication.
DELETED
appears
on
the
last
record
when
It
is
a
record
saved
from
a
STORE
or
DELETE
function.
A
record
with
the
“DELETED”
status
cannot
be
modified.
Attempting
to
do
so
will
display
an
error
message:
“CANNOT
MODIFY
DELETED
STEP”.
i MOVES ..... —This message tells you to rotate the kK OR DELAY
control to move an underline through menu-display fields that can be
changed by rotating the -| control.
-4 ALTERS CHAR—Thls message tells you to rotate the -4 control to
change the Information in the selected (underlined) field.
ERASE NAME—Erases the name currently displayed.
TOGGLE STATUS—Toggles status of record between blank and END
SEQ. Select END SEQ to mark a record as the last In a sequence.
RETURN—Returns to the Store/Recall Setup menu.
Recovering A Deleted Setup
A setup deleted by a STORE or DELETE functlon Is saved In the store/
recall memory for recovery. Only the last deleted setup may be recovered.
Recovery must be done before the STORE or DELETE functions are used
again. Also, a setup should be recovered before using the INSERT NEXT
function
when
there
are
already
19
or
more
stored
setups.
A
setup
that
Is
deleted
by
the
STORE
function
when
20
setups
are
stored
is
not
saved
and
cannot be recovered.
