Operators Familiarization
Press
the
STORE/RECALL
SETUP
button
to
call
up
the
Store/Recall
Setup
menu.
Rotate
the
—{
control
to
review
the
stored
setups.
Determine
whether
there
are
enough
EMPTY
locations
to
store
all
of
the
setups
In
your
sequence.
There
are
a
total
of
20
locations
available.
It
Is
a
good
idea
to
use
only
19
and
leave
the
20th
open
so
that
the
system
will
have
a
place
to
store
the
last
deleted
file
for
recovery
when
necessary.
If
there
are
not
enough
locations
available
to
store
your
setups,
you
can
use
DELETE
to
remove
unneeded
setups
or
you
can
use
the
STORE
function
to
“write”
over
them.
Set
the
front-panel
controls
as
desired
for
the
first
setup
In
your
sequence.
Set
all
controls
the
way
you
want
them;
even
the
Intensity
control
settings
can
be
stored
for
recall.
You
can
set
the
front-panel
controls
In
several
ways:
setting
the
Individual
controls
manually,
Inputting
the
desired
signals
and
pressing
the
AUTO
SETUP
button,
or
by
recalling
and
modifying
an
already
stored
setup.
Rotate
the
|
control
to
the
setup
location
that
Is
to
precede
or
start
the
first
setup
In
the
sequence.
Press
INSERT
NEXT
(or
STORE,
If
the
current
setup
location
Is
to
be
“written”
over).
Press
ALTER
LABELS
to
call
up the
ALTER
LABELS
menu
and
give
the
desired
name
to
your
setup.
Also
make
sure
that
the
status
Is
blank
for
all
of
the
setups
In
the
sequence,
except
the
last
one,
and
that
one
should
be
END
SEQ.
END
SEQ
Is
used
to
mark
the
last
setup
In
a
sequence
using
the
ALTER
LABELS
function.
Press RETURN to display the Store/Recall Setup menu.
Repeat
the
above
process
of
Inserting
or
storing
(writing
over)
until
all
the
setups
in
your
sequence
are
stored
In
memory.
lf your sequence did not begin at setup location 01, use the ALTER
LABELS menu to alter the status of the setup Just preceding your first
setup In the sequence to END SEQ.
2247A Operators 3-51
