Replaceable Mechanical Parts—485
Fig. &
Index
No.
Tektronix
Part No.
Serial/Model No.
Eft Dscont
Qty
1 2 3 4 5 Name & Description
Mfr
Code
Mfr Part Number
1-1 200-1268-01
1
ADAPTER, CAMERA: 80009
200-1268-01
(ATTACHING PARTS)
-2 211-0195-00 4 SCREW,MACHINE:4-40 X 0.875 INCH,STL
83385
OBD
337-1497-00
8010100 B010149X
1 SHLD,IMPLOSION: 80009
337-1497-00
-3 331-0295-00
1 MASK,CRT SCALE:GRATICULE
80009
331-0295-00
-4
366-1166-00
1
KNOB:RED
80009
366-1166-00
213-0153-00
1 . SETSCREW:5—40 X 0.125 INCH,HEX SOC STL
74445 OBD
-5 366-1338-00
1
KNOB:GRAY 80009 366-1338-00
213-0153-00
2 . SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-6
366-1168-00
1
KNOB:BLACK CAP AND RED BODY
80009
366-1168-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-7 366-1385-00 B010100
B089999 1
KNOB:GRAY
80009
366-1385-00
366-1385-01
B090000
B142149 1
KNOB:GRAY
80009
366-1385-01
366-1385-00
B142150
1
KNOB:GRAY 80009
366-1385-00
213-0243-00 B010100
B089999
2 . SETSCREW:5-40 X 0.25 INCH,HEX SOC STL
70276
OBD
377-0293-01
B090000 B142149
1
. INSERT,KNOB:INTERLOCKING
80009
377-0293-01
213-0243-00
B142150
2
. SETSCREW:5-40 X 0.25 INCH,HEX SOC STL
70276 OBD
-8
354-0413-00
1
RING,KNOB SKIRT.-1.75 INCH OD,PLASTIC
80009 354-0413-00
213-0218-00
1
. SETSCREW:6-32 X 0.25 INCH,HEX SOC STL
74445
OBD
-9
366-1166-00
1
KNOB:RED 80009
366-1166-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-10 366-1338-00
1 KNOB: GRAY
80009
366-1338-00
213-0153-00
1 . SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-11
366-0494-00
1
KNOB:GRAY
80009
366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-12 366-0494-00
1 KNOB:GRAY
80009 366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445 OBD
-13
366-0494-00
1
KNOB:GRAY
80009 366-0494-00
213-0153-00
1 . SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-14
366-0215-02
7
KNOB:LEVER SWITCH
80009
366-0215-02
-15 366-0494-00
1
KNOB:GRAY 80009
366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445 OBD
-16 366-0494-00
1
KNOB:GRAY 80009
366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-17
366-1391-00
1
KNOB:GRAY
80009
366-1391-00
213-0239-00
1
. SETSCREW:3-48 X 0.062 INCH,HEX SOC STL
71159
OBD
-18
366-1315-00
1
KNOB:GRAY
80009 366-1315-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-19 366-0494-00
1
KNOB:GRAY
80009
366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-20 366-0392-00
1
KNOB .-GRAY
80009
366-0392-00
-21 366-1391-00
1
KNOB:GRAY
80009
366-1391-00
213-0239-00
1
. SETSCREW:3-48 X 0.062 INCH,HEX SOC STL
71159
OBD
-22
366-1315-00
1
KNOB:GRAY
80009 366-1315-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-23 331-0328-00
1
DIAL,CONTROL: 10 TURN FOR 0.25 DIA SHAFT
05129 461-S-70
213-0048-00
1
. SETSCREW:4—40 X 0.125 INCH,HEX SOC STL
74445
OBD
-24
366-0494-00
1
KNOB:GRAY
80009
366-0494-00
213-0153-00
1
. SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
74445
OBD
-25
426-0785-00
17 FR.PUSH BUTTON:GRAY PLASTIC
80009
426-0785-00
-26 378-0690-03
1 LENS , LIGHT: AMBER— 20MHZ
80009 378-0690-03
-27
378-0690-04
2
LENS,LIGHT:AMBER— RESET
80009 378-0690-04
-28
378-0690-05
1
LENS, LIGHT: AMBER-READY
80009 378-0690-05
-29 378-0690-06
1 LENS,LIGHT:AMBER— TRIG'D
80009 378-0690-06
-30 358-0301-02
2
BUSHING,SLEEVE:GRAY PLASTIC
80009
358-0301-02
-31 358-0378-00
2 BUSHING,SLEEVE:PRESS MOUNT
80009 358-0378-00
129-0053-00
1
POST,BDG,ELEC:UNINSULATED
80009 129-0053-00
-32
355-0507-00
1
. STUD,SHOULDERED:BINDING POST
80009 355-0507-00
-33 200-0103-00
1
. NUT,PLAIN,KNURL:0.25-28 X 0.375” OD,BRASS
80009 200-0103-00
(ATTACHING PARTS)
-34
210-0583-00
1
NUT,PLAIN,HEX.:0.25-32 X 0.312 INCH,BRS
73743
2X20224-402
-35 210-0046-00
1
WASHER,LOCK:INTL,0.26 ID X 0.40" OD,STL
78189
1214-05-00-0541C
