Tektronix 5 Series MSO

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-19 065-1024-XX Below B020000
Below C040000
1 MODULE ASSY: SERVICE REPLACEMENT KIT; FRONT PANEL
8781
144XX AND 259022300
Return the instrument to Tektronix for service.
065-1072-XX B020000 and above
C040000 and above
1 MODULE ASSY; SERVICE REPLACEMENT KIT; FRONT PANEL LED
8781719XX AND 2590245XX
Return the instrument to Tektronix for service.
-20 260-3144-XX 1 SWITCH, KEYPAD, ELASTOMERIC
Return the instrument to Tektronix for service.
-21 174-6880-XX 1 CABLE, FFC, FRONT-PANEL TO PIB
Return the instrument to Tektronix for service.
-22 351-1150-XX - GUIDE, PROBE VPI PLUS
Return the instrument to Tektronix for service.
4 4 channel quantity
6 6 channel quantity
8 8 channel quantity
-23 335-3680-XX 1 MARKER IDENTIFICATION, LABEL FRONT PANEL, MSO, 4
CHANNEL, SAFETY CONTROLLED
335-3678-XX 1 MARKER IDENTIFICATION, LABEL FRONT PANEL, MSO, 6
CHANNEL, SAFETY CONTROLLED
335-3676-XX 1 MARKER IDENTIFICATION, LABEL FRONT PANEL, MSO, 8
CHANNEL, SAFETY CONTROLLED
-24 366-0946-XX 1 ASSEMBLY, KNOB, PAN WITH OVERMOLD
-25 358-0890-XX 1 BUSHING, SPACER, RING JOG-SHUTTLE
-26 366-0947-XX 1 ASSEMBLY, KNOB, ZOOM WITH OVERMOLD
-27 366-0944-XX 2 ASSEMBLY, KNOB, MEDIUM WITH OVERMOLD
-28 366-0943-XX 2 ASSEMBLY, KNOB, SMALL WITH OVERMOLD
-29 366-0945-XX 2 ASSEMBLY, KNOB, LARGE WITH OVERMOLD
-30 335-3681-XX 1 MARKER IDENTIFICATION, LABEL PROBE INTERFACE MSO 4CH,
SAFETY CONTROLLED
335-3679-XX 1 MARKER IDENTIFICATION, LABEL PROBE INTERFACE MSO 6CH,
SAFETY CONTROLLED
335-3678-XX 1 MARKER IDENTIFICATION, LABEL FRONT PANEL, MSO, 6
CHANNEL, SAFETY CONTROLLED
Table continued…
Replaceable parts
5 Series MSO Service Manual MSO54, MSO56, MSO58 49
