Tektronix AFG3000 Series Technical Reference

Specifications
Table 10: Output ch aracteristics (cont.)
Characteristic Description
PV reference
page
AFG3021B / 3021C /
3022B / 3022C
10 Hz ≤ frq < 20 kHz: < –70 dBc
20 kHz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq < 10 MHz: < –50 dBc
10 MHz ≤ frq ≤ 25 MHz: < –40 dBc
AFG3051C / 3052C 10 Hz ≤ frq < 20 kHz: < –70 dBc
20 kHz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq < 5 M Hz: < –50 dBc
5MHz≤ frq ≤ 50 MHz: < –40 dBc
AFG3101 / 3101C / 3102
/ 3102C
10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq < 5 M Hz: < –50 dBc
5MHz≤ frq ≤ 100 MHz: < –37 dBc
AFG3251 / 3251C / 3252
/ 3252C
10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq < 5 M Hz: < –50 dBc
5MHz≤ frq < 25 MHz:< –37 dB c
25 MHz ≤ frq ≤ 240 MHz: < –30 dBc
Total h
armonic d istortion
(at 1 V
p-p
amplitude)
10 Hz to 20 kHz: < 0.2% (See page 59,
Total Harmonic
Distortion test.)
Spurious
1
(nonharmonic) (at 1 V
p-p
amplitude)
(See page 61,
Spurious test.)
AFG3011 / 3011C 10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq ≤ 10 MHz: < –50 dBc
AFG3021B / 3021C /
3022B / 3022C
10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq ≤ 25 MHz: < –50 dBc
AFG3051C / 3052C 10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq ≤ 50 MHz: < –50 dBc
AFG3101 / 3101C / 3102
/ 3102C
10 Hz ≤ frq < 1 MHz: < –60 dBc
1MHz≤ frq < 25 MHz: < –50 dBc
25 MHz ≤ frq ≤ 100 MHz: –50 dBc + 6 dBc/octave
AFG3251 / 3251C / 3252
/ 3252C
10 Hz ≤ frq < 1 MHz: < –50 dBc
1MHz≤ frq < 25 MHz: < –47 dBc
25 MHz ≤ frq ≤ 240 MHz: –47 dBc + 6 dBc/octave
Phase noise, typical (at 1 V
p-p
amplitude)
AFG3011 / 3011C 10 MHz: < –110 dBc/Hz at 10 kHz offset
AFG3021B / 3021C /
3022B / 3022C / 3051C
/ 3052C / 3101 / 3101C /
3102 / 3102C
20 MHz: < –110 dBc/Hz at 10 kHz offset
Residual clock noise, typical
AFG3011 / 3011C /
3021B / 3021C / 3022B /
3022C / 3051C / 3052C
–63 dBm
AFG3000 Series Specifications and Performance Verification 11
