Tektronix AFG3000 Series Technical Reference

Specifications
Table 10: Output characteristics (cont.)
Characteristic Description
PV reference
page
AFG3101 / 3101C / 3102
/ 3102C / 3251C / 3251C
/ 3252 / 3252C
–57 dBm
Square wave
Rise time/
fall time
(See page 64,
Rise-Fall time
test.)
AFG3011 / 3011C
≤ 50 ns
AFG3021B / 3022B
≤ 18 ns
AFG3021C / 3022C
≤ 9ns
AFG3051C / 33052C
≤ 7ns
AFG3101 / 3101C / 3102
/ 3102C
≤ 5ns
AFG3251 / 3251C / 3252
/ 3252C
≤ 2.5 ns
Jitter (rms), typical
AFG3011 / 3011C /
3021B / 3021C / 3022B /
3022C
500 ps
AFG3051C / 33052C
300 ps
AFG3101 / 3101C / 3102
/ 3102C
200 ps
AFG3251 / 3251C / 3252
/ 3252C
100 ps
Pulse
Pulse width
AFG3011 / 3011C
80 ns to 999.99 s
AFG3021B / 3021C /
3022B / 3022C
16 ns to 999.99 s
AFG3051C / 33052C
12 ns to 999.99 s
AFG3101 / 3101C / 3102
/ 3102C
8 ns to 999.99 s
AFG3251 / 3251C / 3252
/ 3252C
4 ns to 999.99 s
Resolution 10 ps or 5 digits
Pulse duty
0.001% to 99.999%
Leading edge/trailing edge transition time (at 10% to 90% of amplitude, respectively)
AFG3011 / 3011C 50 ns to 0.625 * pulse period
AFG3021B / 3022B 18 ns to 0.625 * pulse period
12 AFG3000 Series Specifications and Performance Verification
