Tektronix AFG3000 Series Technical Reference

Specifications
Table 10: Output ch aracteristics (cont.)
Characteristic Description
PV reference
page
AFG3021C / 3022C 9 ns to 0.625 * pulse period
AFG3051C / 33052C 7 ns to 0.625 * pulse period
AFG3101 / 3101C / 3102
/ 3102C
5 ns to 0.625 * pulse period
AFG3251 / 3251C / 3252
/ 3252C
2.5 ns to 0.625 * pulse period
Resolution 10 ps or 4 digits
Overshoot, typical < 5%
Jitter (rms), typical
AFG3011 / 3011C /
3021B / 3021C / 3022B /
3022C
500 ps
AFG3051C / 33052C
300 ps
AFG3101 / 3101C / 3102
/ 3102C
200 ps
AFG3251 / 3251C / 3252
/ 3252C
100 ps
Ramp
Linearity (at frequency: 1 kHz, amplitude: 1 V
p-p
, symmetry: 100%)
AFG3011 / 3011C / 3251
/ 3251C / 3252 / 3252C
≤ 0.2% of peak output at 10% to 90% of amplitude range
AFG3021B / 3021C /
3022B / 3022C / 3051C /
3052C
≤ 0.1% of peak output at 10% to 90% of amplitude range
AFG3101 / 3101C / 3102
/ 3102C
≤ 0.15% of peak output at 10% to 90% of amplitude range
Symmetry 0% to 100%
Arbitrary
Rise time/fall time, typical
AFG3011 / 3011C
≤ 80 ns
AFG3021B / 3021C /
3022B / 3022C
≤ 14 ns
AFG3051C / 33052C
≤ 10 ns
AFG3101 / 3101C / 3102
/ 3102C
≤ 8ns
AFG3251 / 3251C / 3252
/ 3252C
≤ 3ns
Jitter (rms), typical
AFG3000 Series Specifications and Performance Verification 13
