Column Column name Description
2 Tektronix part number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial number Column three indicates the serial number at which the part was first
ef
fective. Column four indicates the serial number at which the part was
discontinued. No entry indicates the part is good for all serial numbers.
5 Qty This indicates the quantity of parts used.
6 Name & description An item name is separated from the description by a colon (:). Because
of space limitations, an item name may sometimes appear as
incomplete. Use the U.S. Federal Catalog handbook H6-1 for further item
name identification.
Front cover and rear case
Figure 4: Front cover and rear case exploded view
Replaceable parts
6 Series B MSO MSO64B, MSO66B, MSO68B Service 27
